THS-228-065

Regular price $189.99
/



Two professional instruments in one!

Thermapen IR combines the unparalleled speed and accuracy of the Thermapen Mk4 with the versatility of an instrument-grade infrared sensor for instant non-contact surface readings. Why carry two different thermometers when you can just carry the Thermapen IR?

  • Adjustable emissivity infrared from 0.1 to 1.0
  • Patented auto-rotating display
  • Max/Min infrared displays
  • Foldaway thermocouple probe
  • High accuracy probe to ±0.7°F (±0.4°C)
  • Probe readings in only 2-3 seconds
  • Motion-sensing sleep & wake mode
  • Display temps in °C or °F, 1 or 0.1° resolution
  • Includes NIST-Traceable calibration certificate
  • IP54 (not waterproof like the Thermapen Mk4)

View both infrared and penetration probe readings from either hand in any position with Thermapen IR’s patented 360° auto-rotating display. In Probe mode, set the unit down, and Sleep Mode saves battery life. Pick it up, and it turns on automatically. Close the probe when you’re done and it powers off for storage. Each unit ships with a NIST-traceable calibration certificate for both the probe and infrared so you know it’s accurate.

Thermapen IR is a must-have, versatile tool for restaurants, health inspectors, manufacturing, laboratory, and more.

Specifications
Infrared
Infrared Range -58.0 to 661.8°F (-49.9 to 349.9°C)
Infrared Accuracy ±1.8°F (±1.0°C) from 32 to 212°F (0 to 100°C) otherwise ±3.62°F (±2.0°C) or 2% of reading, whichever is greater
Infrared Response Time 1 second
Distance to Target 5:1 target ratio (5" distance measures a 1" diameter target area)
Emissivity 0.95 default - adjustable from 0.1 to 1
Spectral Range 5 to 16 µm
Auto-Off
30 seconds
Probe
Probe Range -58.0 to 572.0°F (-49.9 to 299.9°C)
Probe Accuracy ±0.7°F (±0.4°C) from -58 to 392°F (-49.9 to 199.9°C) otherwise ±1.8°F (±1.0°C)
Probe Response Time 2-3 seconds (reads to within 1°F of final temperature of an ice bath in 3 seconds)
Probe 0.13 dia. x 4.3 L inches (3.3 x 110 L mm) reduces to 0.06 dia. x 0.60 L inches (1.5 dia. x 1.75 L mm), High Performance Type K Thermocouple
General
Resolution Factory set to 1° (user reconfigurable to 0.1°)
Units °C/°F switchable (user reconfigurable)
Water Resistance* IP54
Battery 2x 3V CR2032 Lithium coin cell, 1,000 hours typical
Sleep Mode 30 seconds after last movement detected in probe mode or after measurement button is released in IR mode
Operating Range -4 to 122°F (-20 to 50°C), max ambient limits of Thermapen body
Display 1 H x 1.54 W inches (25 H x 39 W mm) LCD, rotates 360°
Dimensions 6.18 H x 1.97 W x 0.75 D inches (157 H x 50 W x 19 D mm)
Weight 0.26 lbs (120g)
Certificate Includes NIST-Traceable calibration certificate
